Landing Craft

Koffler’s Landing Craft has been designed for both work and pleasure. It has a wide drop door/ramp in the bow for easy loading and unloading of ATV’s, equipment, or cargo. This boat is available with a flat, shallow-V or deep-V bottom depending on the intended use and water conditions. It is available in several styles, including center console, open tiller and cabin designs with inboard or outboard power. The Landing Craft is built with 5086-H32 and 5052-H32, the finest marine grade aluminum alloys available for maximum strength and durability.

Depending on the boat width, there are seven, nine or eleven stringers running the full length of the bottom for maximum bottom strength. The 3/16″ or 1/4″ bottom is joined to the 1/8″ or 3/16″ ribbed sides by a custom designed extrusion that is double welded for the greatest strength possible. The top gunwhale can be a special extruded handrail or formed, for extra strength and a cleaner fisnished appearance. For best possible quality and performance, the Koffler Landing Craft is continually being tested and improved. Each Koffler Landing Craft is custom built to suit the customer’s needs.

Specifications

Length Beam Bottom Side Height Side Thickness Bottom Thickness
20′ 96″ 72″ 32″ .125 .190
21′ 96″ 72″ 32″ .125 .190
22′ 96″ 72″ 32″ .125 .190
24′ 96″ 84″ 32″ .125 .190
26′ 102″ 84″ 36″ .188 .250
27′” 102″ 84″ 36″ .188 .250
28′ 102″ 84″ 36″ .188 .250
30′ 102″ 84″ 36″ .188 .250

Standard Features

→ Click on underlined standard features listed below to bring up slideshow of images.

.125 Sides with Formed Rib for Strength, 32″ Side Height, 5 to 7 -2″ Channel Reinforcing Stringers Depending on Boat Width, Bi-fold Door with Electric Winch, Extrusion Joining Side & Bottom, 2 Removable Seat Boxes, Formed Gunnels, Full Length Tackle Trays, Aluminum Diamond Plate Floors, Rear Towing Eyes, Transducer Brackets, Zinc Block, Zolatone Interior Paint, Koffler Logo.

Available Options

We have a wide range of options & accessories for your Koffler Boat.
If we don’t have what you’re looking for, we can customize your boat to meet your needs.

→ Click on options listed below to bring up slideshow of images.

❑     34″ or 36″ Sides
❑     Wider Bottom (66″)/(78-84″)
❑     Offshore Bracket
❑     Splash Well
❑     Diamond Plate Bra
❑     Storage Under Floor
❑     Built-In Fish Box
❑     Rod Box
❑     Double Tackle Trays
❑     Transom Tackle Tray
❑     Crab Tray
❑     Transom Battery Enclosure
❑     Sounder Box
❑     Console (Basic Side or Center)
❑     Larger Console with Cover
❑     Windshield on Console (Slide-Up)
❑     Glass Windshield with Metal Frame
❑     Windshield Wiper (Installed)
❑     Cable Steering
❑     Hydraulic Steering
❑     2 – 6 Gallon Fuel Tanks, Under Rear Tray
❑     2 – 65 Gallon Saddle Tanks
❑     42 Gallon Fuel Tank in Floor
❑     61 Gallon Fuel Tank in Floor
❑     102 Gallon Fuel Tank in Floor
❑     Sand Blasted Finish on Floors
❑     Moeller Rod Holders (3 Rods)
❑     Clear Coat on Zolatone (Per Foot)
❑     Exterior Vinyl
❑     Exterior Paint, One Color
❑     Exterior Paint, Additional Colors
❑     Fish On Seat with Pad
❑     4 Legged Pedestal (Seat Not Included)
❑     Removable 20″ x 20″ Seat Box
❑     Sliding Seat Boxes (Per Pair)
❑     Rubber Gunnel Guard (Per Foot)
❑     Running Lights
❑     Bilge Pump
❑     Wash Down Pump (Plumbed into Fish Box)
❑     Hand Wash Sink
❑     Dual Batteries with Switch
❑     Courtesy Lights (4)
❑     Grab Handle
❑     Swim Step
❑     Stainless Steel Dive Ladder or 3 Step Ladder
❑     Crab Davit
❑     Crab Davit Hand Winch
❑     Heavy Duty Davit Hand Winch
❑     Electric Crab Pot Puller
❑     Cigarette Lighter & Map Light
❑     12 Volt Plug or USB
❑     Dierk’s with Cleat
❑     Koffler River Anchor System with Anchor
❑     50′ Anchor Rope
❑     R&D Baker Single Axle Trailer (18′-20′)
❑     Koffler Galv. Single Axle Trailer (18′-20′)
❑     R&D Baker Tandem Axle (22′ x 84″)
❑     Koffler Galv. Tandem Axle Trailer (20′-24′)
❑     Koffler Galv. Tandem Axle Trailer (26′-28′)
❑     Aluminum Trailer Upgrade
❑     Ratchet Tie Down Straps
❑     Electric Brakes (Per Axle)
❑     Surge Brakes (Per Axle)
❑     14″ Spare Tire & Wheel

Customer’s Boats

Look through these customer’s boats to see examples to help you design your own boat.
